The STTH12R06, which is using ST Turbo 2 600V technology, is specially suited as boost diode in continuous mode power factor corrections and hard switching conditions.

This device is also intended for use as a free wheeling diode in power supplies and other power switching applications.

STTH12R06，这是采用ST涡轮2 600V的技术，是特别适合作为升压二极管在连续模式功率因数校正和硬开关条件。

该装置还提供了一个续流二极管在电源和其他电源转换应用。

Key Features

• Ultrafast switching

• Low reverse recovery current

• Low thermal resistance

• Reduces switching losses

• Package insulation voltage:

  TO220AC Ins: 2500 V_RMSTO-220FPAC: 2000 V_DC

主要特点

超快切换

低反向恢复电流

低热阻

减少开关损耗

包绝缘电压：to220ac插件：2500 vrmsto-220fpac：2000 VDC
