Dual power Schottky rectifier suited for switched mode power supply and high frequency DC to DC converters.

Packaged in ISOTOP, this device is especially intended for use in low voltage, high frequency inverters, free wheeling and polarity protection applications.

适用于开关电源和高频直流-直流转换器的双功率肖特基整流器。

用同位素，该装置特别适用于低电压，高频率逆变器，免费续流和极性保护中的应用。

Key Features

• VERY SMALL CONDUCTION LOSSES

• NEGLIGIBLE SWITCHING LOSSES

• EXTREMELY FAST SWITCHING

• LOW THERMAL RESISTANCE

• INSULATED PACKAGE:

  Insulating voltage = 2500 V_(RMS)Capacitance = 45 pF

主要特点

很小的传导损耗

可忽略的开关损耗

极快速切换

低热阻

绝缘包：绝缘电压为2500伏（均方根）电容= 45
