Single Schottky rectifier suited to switched mode power supplies and high frequency DC to DC converters.

Packaged in SMA and SMB, this device is especially intended for use in parallel with MOSFETs in synchronous rectification and low voltage secondary rectification.

适合于开关电源和高频直流-直流转换器的单肖特基整流器。

包装在SMA、SMB、该设备是用于同步整流和低电压次级整流MOSFET并联使用。

Key Features

• Very low forward voltage drop for less power dissipation

• Optimized conduction/reverse losses trade-off which means the highest yield in the applications

• Surface mount miniature packages

• Avalanche capability specified

主要特点

非常低的正向压降为较少的功耗

优化的传导/反向损失的权衡，这意味着在应用程序中的最高产量

表面贴装微型封装

规定的雪崩能力
