These 150 V power Schottky rectifiers are suited for switch mode power supplies on up to 24 V rails and high frequency converters.

Packaged in STmite/STmite flat, SMA and axial, this device is intended for use in consumer and computer applications like TV, STB, PC and DVD where low drop forward voltage is required to reduce power dissipation.

这150伏的功率肖特基整流器适用于高达24伏的高频率转换器的开关模式电源供应。

包装在stmite / stmite平、SMA和轴，此设备是用于消费和计算机的应用，如电视、机顶盒、个人电脑和DVD在低压降电压需要降低功耗。

Key Features

• Negligible switching losses

• Low forward voltage drop for higher efficiency and extended battery life

• Low thermal resistance

• Surface mount miniature package

• Avalanche capability specified

• ECOPACK^®2 compliant component

主要特点

可忽略的开关损耗

低正向压降，以提高效率和延长电池寿命

低热阻

表面贴装微型封装

规定的雪崩能力

®Ecopack 2兼容的组件
