Key Features

  200 MHz/330 DMIPS, microAptiv core

  DSP-enhanced core:

  Four 64-bit accumulators

  Single-cycle MAC, saturating and fractional math

  Dual Panel Flash for live update support

  10-bit, 500 KSPS, 40-channel ADC module

  Memory Management Unit for optimum embedded OS execution

  microMIPS mode for up to 35% code compression

  UART, I2C, PMP, EBI, SQI & Analog Comparators

  SPI/I2S interfaces for audio processing and playback

  Hi-Speed USB Device/Host/OTG

  10/100 Mbps Ethernet MAC with MII and RMII interface

  Temperature Range: - 40°C to 85°C; - 40°C to 125°C (planned)

Microcontroller Features

  Operating voltage range of 2.2V to 3.6V

  1MB Flash memory (plus an additional 160 KB of Boot Flash)

  512KB SRAM memory

  microMIPS mode for up to 35% smaller code size

  DSP-enhanced core:

  Four 64-bit accumulators

  Single-cylce MAC, saturating and fractional math

  Code-efficient (C and Assembly) architecture

  Low-power management modes (Idle and Sleep)

Peripheral Features

  50 MHz External Bus Interface (EBI)

  50 MHz Serial Quad Interface (SQI)

  Peripheral Pin Select (PPS) functionality to enable function remap

  8 channels of hardware programmable DMA and 12 channels of dedicated DMA with automatic data size detection

  Six UART modules (25 Mbps): Supports LIN 1.2 and IrDA protocols

  Six 4-wire SPI modules (50 Mbps)

  SQI configurable as an additional SPI module (50 MHz)

  Five I2C modules (up to 1 Mbaud) with SMBus support

  Parallel Master Port (PMP)

  Hardware Real-Time Clock and Calendar (RTCC)

  Nine 16-bit Timers/Counters (four 16-bit pairs combine to create four 32-bit timers)

  Nine Capture inputs and Nine Compare/PWM outputs

Audio/Graphics/Touch HMI Features

  Graphics interface: EBI or PMP

  Audio data communication: I2S, LJ, RJ, USB

  Audio data control interface: SPI and I2C™

  Audio data master clock: Fractional clock frequencies with USB synchronization

Advanced Analog Features

  10-bit ADC Module:

  500 Ksps rate with One Sample and Hold (S&H) circuits

  Up to 40 analog inputs

  Flexible and independent ADC trigger sources

  6 digital filters and comparators

  Two comparators with 32 programmable voltage references

  Temperature sensor with ±2°C accuracy

Debugger Development Support

  In-circuit and in-application programming

  4-wire MIPS® Enhanced JTAG interface

  Unlimited program and 12 complex data breakpoints

  IEEE 1149.2-compatible (JTAG) boundary scan

  Non-intrusive hardware-based instruction trace
