MCU Core

   80MHz/105DMIPS, 32-bit MIPS M4K® Core

   USB 2.0 On-The-Go Peripheral with integrated PHY

   10/100 Ethernet MAC with MII/RMII Interfaces

   2 x CAN2.0b modules with 1024 buffers

   8 Dedicated DMA Channels for USB OTG, Ethernet, and CAN

   5 Stage pipeline, Harvard architecture

   MIPS16e mode for up to 40% smaller code size

   Single cycle multiply and hardware divide unit

   32 x 32-bit Core Registers

   32 x 32-bit Shadow Registers

   Fast context switch and interrupt response

MCU System Features

   512K Flash (plus 12K boot Flash)

   128K RAM (can execute from RAM)

   8 Channel General Hardware DMA Controller

   Flash prefetch module with 256 Byte cache

   Lock instructions or data in cache for fast access

   Programmable vector interrupt controller

Analog Features

   Fast and Accurate 16 channel 10-bit ADC,

   Max 1 Mega sample per second at +/- 1LSB, conversion available during SLEEP & IDLE

Power Management Modes

   RUN, IDLE, and SLEEP modes

   Multiple switchable clock modes for each power mode, enables optimum power settings

Debug Features

   iFlow Trace: Non-intrusive Hardware Instruction Trace port (5 Wires)

   8 hardware breakpoints (6 Instruction and 2 Data)

   2 wire programming and debugging interface

   JTAG interface supporting Programming, Debugging and Boundary scan

Other MCU Features

   Fail-Safe Clock Monitor - allows safe shutdown if clock fails

   2 Internal oscillators (8MHz & 31KHz)

   Hardware RTCC (Real-Time Clock and Calendar with Alarms)

   Watchdog Timer with separate RC oscillator

   Pin compatible with 16-bit PIC® MCUs

   Serial Communication Modules allow flexible UART/SPI/I2C™ configuration
