Ideal for low power (<100nA standby current) and connectivity applications that benefit from the availability of multiple serial ports (3xI2C, 3xSPI), 4xUARTS, and 23 independent timers. Large amounts of RAM (16kB) memory for buffering and large (up to 256kB) Enhanced Flash program memory make it ideal for embedded control and monitoring applications. PPS (Peripheral Pin Select) aids in configuring the most efficient pin configuration of available I/O, and CTMU provides touch sensing support for up to 64 individual buttons.Available in 64, 80, and 100 pin packages

CPU

  Up to 16 MIPS performance

  16 x 16 Hardware Multiply, Single Cycle Execution

  12-bit x 16-bit Hardware Divider

  C Compiler Optimized Instruction Set

nanoWatt Power Managed Modes

  Run, Idle and Sleep modes

  Multiple, Switchable Clock Modes for Optimum Performance and Power Management

  Run mode: 1 mA/MIPS, 2.0V Typical

  Sleep mode Current Down to 100 nA Typical

  Standby Current with 32 kHz Oscillator:2.5 uA,2.0V typical

Flash Program Memory

  Self-Reprogrammable under Software Control

  10,000 erase/write cycles

  20 year data retention

  EEprom emulation capable

System

  Internal oscillator support - 31 kHz to 8 MHz, up to 32 MHz with 4X PLL

  On-chip LDO Voltage Regulator

  JTAG Boundary Scan and Flash Memory Program Support

  Fail-Safe Clock Monitor – allows safe shutdown if clock fails

  Watchdog Timer with separate RC oscillator

Analog Features

  10-bit ADC, 16 channels, 500k samples per second

  Three Analog comparators

Peripherals

  CTMU supports Capacitive Touch applications

  Perpheral Pin Select allows I/O remapping of many peripherals in real time

  4xUART Modules with LIN and IrDA support, 4 Deep FIFO

  3xSPI ™ Modules with 8 Deep FIFO

  3xI2C™ Modules with Master and Slave Modes

  Five 16-bit Timer Modules

  Up to 9 Input Capture and 9 Output Compare/PWM with dedicated time base

  Hardware RTCC, Real-Time Clock Calendar with Alarms

  PMP, Parallel Master Port, with 16 Address Lines, and 8/16-bit Data
