Debug Support
• Integrated debug support on Device.No debug header is required
• Optional external debug headers, AC244043 (F) / AC244044 (LF), are also available
• Debug and programming support is available viaPICkit™ 3, and MPLAB® ICD 3
• For Debug Header information, please refer to

  Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels

  Flash Program Memory with self read/write capability

  Internal 32MHz oscillator

  Integrated Capacitive mTouch Sensing Module

  Data Signal Modulator for generation of custom bit streams

  CVREF can be used as 5-bit DAC

  MI2C, SPI, EUSART w/auto baud

  2 ECCP & 2 CCP (Enhanced/Capture Compare PWM)

  Comparators with selectable Voltage Reference

  12 Channel 10b ADC with Voltage Reference

  25mA Source/Sink current I/O

  Four 8-bit Timers (TMR0/TMR2/TMR4/TMR6)

  One 16-bit Timer (TMR1)

  Extended Watchdog Timer (EWDT)

  Enhanced Power-On/Off-Reset

  Brown-Out Reset (BOR)

  In Circuit Serial Programming (ICSP)

  On Board In-Circuit Debug

  Wide Operating Voltage (1.8V – 5.5V)

  Low Power PIC16LF182x variants (1.8V – 3.6V)

  Standby Current (PIC16LF182X): 30 nA @ 1.8V, typical
