PIC16(L)F161X microcontrollers deliver on-chip features that are unique to the design for embedded control of small motors and general purpose applications in 8 / 14 / 20 pin count packages.   Features like 10-bit A/D, CCP, 24-bit SMT, Zero Cross Detection offer an excellent solution to variety of applications.  The product family also has a CRC + memory scan and Window WDT to support safety critical systems in home appliances, white goods and other end equipment.

  Flash Program Memory with self read/write capability

  Enhanced Mid-Range Core, Internal 32MHz oscillator

  High Endurance Flash Memory (HEF)

  128 B of Non-volatile Data Storage

  2 x Analog Comparators

  2 x 10-bit PWM

  2 x Capture-Compare-PWM (CCP)

  8 x 10-bit Analog-to-Digital Converter (ADC) with voltage reference

  Complementary Waveform Generator (CWG):

  Zero Cross Detection (ZCD)

  CRC:  16-bit with DMA

  Math Accelerator

  Timers:

  2 x 24-bit Signal Measurement Timer (SMT)

  3 x Hardware Limit Timer (HLT)

  Angular Timer

  Window Watchdog Timer (WWDT)

  High Current Source/Sink: 2 x 100mA I/O

  Power-On Reset (POR), Brown-Out Reset (BOR)

  In Circuit Serial Programming (ICSP)

  Wide Operating Voltage of PIC16F1618 variant (2.3V – 5.5V)

  Enhanced Low-Voltage PIC16LF1618 variant (1.8V - 3.6V)
