Debug Support
• Integrated debug support on Device. No Debug Header is required
• Debug and Programming support is available via PICkit™ 3, and MPLAB® ICD 3

  Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels

  Flash Program Memory with self read/write capability

  High Endurance Flash Memory (HEF)

  128 B of Non-volatile Data Storage

  Internal 16MHz oscillator

  MI2C, SPI, EUSART w/auto baud

  Two CCP (Capture Compare PWM) Module

  28 Channel 10-bit ADC with Voltage Reference

  25mA Source/Sink current I/O

  Two 8-bit Timers (TMR0/TMR2)

  One 16-bit Timer (TMR1)

  Extended Watchdog Timer (WDT)

  Enhanced Power-On/Off-Reset

  Programmable Ultra Low-Power Brown-Out Reset (ULPBOR)

  In Circuit Serial Programming (ICSP)

  In-Circuit Debug

  Wide Operation Voltage Variant ‘F’ (2.3V – 5.5V)

  eXtreme Low Power (XLP) ‘LF’ Variant (1.8V – 3.6V)
