Debug Support
• Integrated debug support on Device.No Debug Header is required
• Debug and Programming support is available viaPICkit™ 3, and MPLAB® ICD 3

  Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels

  Flash Program Memory with self read/write capability

  High Endurance Data Flash block in lower 128 bytes of Program Memory(100,000 W/ECycles)

  Internal 16MHz oscillator

  MI2C, SPI, EUSART w/auto baud

  Two CCP (Capture Compare PWM) Module

  17 Channel 10-bit ADC with Voltage Reference

  25mA Source/Sink current I/O

  Two 8-bit Timers (TMR0/TMR2)

  One 16-bit Timer (TMR1)

  Extended Watchdog Timer (WDT)

  Enhanced Power-On/Off-Reset

  Programmable Ultra Low-Power Brown-Out Reset (ULPBOR)

  In Circuit Serial Programming (ICSP)

  In-Circuit Debug

  PIC16LF1518 (1.8V – 3.6V)

  PIC16F1518 (2.3V – 5.5V)
