The NE570 Compandor is a versatile low cost dual gain control circuit in which either channel may be used as a dynamic range compressor or expandor. Each channel has a full-wave rectifier to detect the average value of the signal, a linerarized temperature-compensated variable gain cell, and an operational amplifier. The NE570 is well suited for use in cellular radio and radio communications systems, modems, telephone, and satellite broadcast/receive audio systems.

• Complete Compressor and Expandor in One IC
• Temperature Compensated
• Greater than 110 dB Dynamic Range
• Operates Down to 6.0 VDC
• System Levels Adjustable with External Components
• Distortion may be Trimmed Out
