The NCV7608 integrates 8 output drivers configurable in any combination of highside, lowside, or full bridge configurations. The integrated standard Serial Peripheral Interface (SPI) allows digital control of all outputs stages and provide diagnostic fault information.In addition, four channels (CH5 to CH8) can be PWM controlled via external control input pins. Integrated clamping circuits (both in high and low side operational modes), waveshaping, positive and negative transient protection, and dedicated channel pair overtemperature shutdown circuits provide for a wide range of automotive and industrial applications.

• Eight Independent Configurable Drivers
• RDS(on) = 1.2 (typ @25 C)
• 5 MHz SPI Interface for Data Communication
• 16 Bit Frame Length, Daisy Chain Compatible
• 3.3 V or 5 V Compatible
• PWM Inputs for 4 Outputs
• Ultra low Standby Current
• Over Current Protection (Characterized to AEC Q10X 12 REV A)
• High Side and Low Side Flyback Protection
• Fault Reporting
• Undervoltage Lockout (VS and VCC)
• Overvoltage Shutdown (VS)
• Supports LED Loads
• Supports Cold Cranking Operation Down to 3 V
• Overtemperature Protection
