The NCP1392B is a self-oscillating high voltage MOSFET driver primarily tailored for the applications using half bridge topology. Due to its proprietary high-voltage technology, the driver accepts bulk voltages up to 600 V. Operating frequency of the driver can be adjusted from 25 kHz to 480 kHz using a single resistor. Adjustable Brown-out protection assures correct bulk voltage operating range. An internal 100 ms PFC delay timer guarantee that the main downstream converter will be turned on in the time the bulk voltage is fully stabilized. The device provides fixed dead time which helps lowering the shoot-through current.

• Minimum frequency adjust accuracy3 %
• Brown-out input
• 100 ms PFC delay timer
• 1 A / 0.5 A Peak Current Sink / Source Drive
• Fixed Dead TimeAvailable in 0.3 us, 0.6 us, & 1.1 us
