ON Semiconductor's NCN49597 is a power line carrier modem using spread-FSK (S-FSK) modulation for robust low data rate communication over power lines. NCN49597 is built around an ARM processor core, and includes the MAC layer. With this robust modulation technique, signals on the power lines can pass long distances.The half-duplex operation is automatically synchronized to the mains, and can be up to 4800 bits/second. The product configuration is done via its serial interface, which allows the user to concentrate on the development of the application. The NCN49597 is implemented in ON Semiconductor mixed signal technology, combining both analog circuitry and digital functionality on the same IC.

• Dual S-FSK channel, each @ 4800 Baud
• Half duplex Power Line Carrier Modem for 50 and 60 Hz mains
• Embedded Cortex M0 processor, programmable embedded software
• Compliant with CENELEC EN 50065-1 & EN 50065-7
• Programmable Carrier Frequencies in CENELEC A, B, C and D Band
• Data Rate selectable:
• 300600120024004800 baud (@ 50 Hz);
• 360720144028805760 baud (@ 60 Hz)
• UART for interfacing with an application microcontroller
• Power supply 3.3 V
• Ambient temperature range: -40°C to +125°C
