The MP34DT04 is an ultra-compact, low-power, omnidirectional, digital MEMS microphone built with a capacitive sensing element and an IC interface.

The sensing element, capable of detecting acoustic waves, is manufactured using a specialized silicon micromachining process dedicated to produce audio sensors.

The IC interface is manufactured using a CMOS process that allows designing a dedicated circuit able to provide a digital signal externally in PDM format.

The MP34DT04 has an acoustic overload point of 120 dBSPL with a 64 dB signal-to-noise ratio and –26 dBFS sensitivity.

The MP34DT04 is available in a top-port, SMD-compliant, EMI-shielded package and is guaranteed to operate over an extended temperature range from -40 °C to +85 °C.

mp34dt04这是一种超小型、低功耗、全方位、数字MEMS麦克风与电容式传感元件和一个集成电路接口构建。

传感元件，能够检测声波，是使用专门的硅微机械加工工艺，专门生产音频传感器制造的。

IC接口是使用CMOS工艺，设计专用的电路能够提供外部PDM格式数字信号制作。

有120的mp34dt04 dBSPL具有64 dB的信噪比和–26 DBFS灵敏度声学超载点。

是的mp34dt04顶口，可用贴片兼容，EMI屏蔽封装，保证工作在扩展温度范围从- 40°C + 85°C.

Key Features

• Single supply voltage

• Low power consumption

• 120 dBSPL acoustic overload point

• 64 dB signal-to-noise ratio

• Omnidirectional sensitivity

• –26 dBFS sensitivity

• PDM output

• HCLGA package

• Top-port design

• SMD-compliant

• EMI-shielded

• ECOPACK^®, ^{RoHS, and “Green” compliant}

主要特点

单电源电压

低功耗

120 dBSPL声学超载点

64分贝信噪比

全方位灵敏度

–26 dBfs的敏感性

PDM输出

hclga包

顶层设计

SMD标准

电磁干扰

®Ecopack，ROHS，和“绿色”标准
