The MP33AB01 is a compact, low-power microphone built with a low-profile sensing element.

The sensing element, capable of detecting acoustic waves, is manufactured using a specialized silicon micromachining process to produce audio sensors.

The MP33AB01 has an acoustic overload point of 125 dBSPL with a 63 dB signal-to-noise ratio.

The MP33AB01 is available in a package compliant with reflow soldering and is guaranteed to operate over an extended temperature range from -30 °C to +100 °C

这mp33ab01是一个紧凑，低功耗的麦克风以低姿态传感元件的建立。

传感元件，能够检测声波，是使用一种专门的硅微机械加工工艺制造的音频传感器制造。

有125的mp33ab01 dBSPL与63 dB的信噪比声学超载点。

的mp33ab01可在一个包装符合回流焊接，保证工作在扩展温度范围从- 30°C + 100°C

Key Features

• Single supply voltage

• Low power consumption

• Omnidirectional sensitivity

• High signal-to-noise ratio

• High bandwidth

• Package compliant with reflow soldering

主要特点

单电源电压

低功耗

全方位灵敏度

高信噪比

高带宽

回流焊封装
