The MCP6V26/7/8 family of operational amplifiers has input offset voltage correction for very low offset and offset drift. These devices have a wide bandwidth product and strongly reject switching noise. They are unity gain stable, have no 1/f noise, and have good PSRR and CMRR. These products operate with a single supply voltage as low as 2.3V and are designed in an advanced CMOS process. AEC-Q100 Grade 1 qualification is available for this device

  High DC Precision:

  VOS Drift: ±50 nV/°C (maximum)

  VOS: ±2 µV (maximum)

  AOL: 133 dB (minimum)

  PSRR: 125 dB (minimum)

  CMRR: 125 dB (minimum)

  Eni: 1 µVp-p (typical), f = 0.1 Hz to 10 Hz

  Eni: 0.32 µVp-p (typical), f = 0.01 Hz to 1 Hz

  Low Power and Supply Voltages:

  IQ: 620 µA/amplifier (typical)

  Wide Supply Voltage Range: 2.3V to 5.5V

  Easy to Use:

  Rail-to-Rail Input/Output

  Gain Bandwidth Product: 2 MHz (typical)

  Unity Gain Stable

  Available in Single and Dual

  Extended Temperature Range: -40°C to +125°C

  AEC-Q100 Grade 1
