The MC10LVEP11 is a differential 1:2 fanout buffer. The device is pin and functionally equivalent to the EP11 device. With AC performance the same as the EP11 device, the LVEP11 is ideal for applications requiring lower voltage. Single ended CLK input operation is limited to a V
>= 3.0 V in PECL mode, or V
The 100 Series contains temperature compensation.

• 240 ps Typical Propagation Delay
• Maximum Frequency > 3 GHz Typical
• PECL Mode Operating Range: V
• = 2.375 V to 3.8 V with V
• = 0 V
• NECL Mode Operating Range: V
• = 0 V with V
• = -2.375 V to -3.8 V
• Open Input Default State
• Q Outputs will default LOW with inputs open or at V
• LVDS Input Compatible
