The MC10H350 is a member of the 10H family of high performance ECL logic. It consists of 4 translators with differential inputs and TTL outputs. The 3-state outputs can be disabled by applying a HIGH TTL logic level on the common OE input.
The MC10H350 is designed to be used primarily in systems incorporating both ECL and TTL logic operating off a common power supply. The separate V
power pins are not connected internally and thus isolate the noisy TTL V
runs from the relatively quiet ECL V
runs on the printed circuit board. The differential inputs allow the H350 to be used as an inverting or noninverting translator, or a differential line receiver. The H350 can also drive CMOS with the addition of a pullup resistor.

• Propagation Delay, 3.5 ns Typical
• MECL 10K Compatible
• Pb-Free Packages are Available
