The MC10/100EP31 is a D flip-flop with set and reset. The device is pin and functionally equivalent to the EL31 and LVEL31 devices. With AC performance much faster than the EL31 and LVEL31 devices, the EP31 is ideal for applications requiring the fastest AC performance available. Both set and reset inputs are asynchronous, level triggered signals. Data enters the master portion of the flip-flop when CLK is low and is transferred to the slave, and thus the outputs, upon a positive transition of the CLK.
The 100 Series contains temperature compensation.

• 340ps Typical Propagation Delay
• Maximum Frequency > 3 GHz Typical
• PECL Mode Operating Range: V
• = 3.0 V to 5.5 V
• with V
• = 0 V
• NECL Mode Operating Range: V
• = 0 V
• with V
• = –3.0 V to –5.5 V
• Open Input Default State
• Q Output will default LOW with inputs open or at V
• Pb-Free Packages are Available
