优势和特点

  Integrated LO Amplifier: +4 dBm Input

  Sub-Harmonically Pumped (x2) LO

  Wideband IF: DC - 4 GHz

  Single Positive Supply: +5V @ 95mA

  24 Lead 4x4mm SMT Package: 16mm²

产品详情

The HMC798ALC4 is a 24 - 34 GHz Sub-harmonically Pumped (x2) MMIC Mixer with an integrated LO amplifier in a leadless RoHS compliant SMT package. The 2LO to RF isolation is excellent at 30 dB, eliminating the need for additional filtering. The LO amplifier is a single bias +5V design with a nominal +4 dBm drive requirement. The RF and LO ports are matched to 50 Ohms for ease of use while the IF covers DC to 4 GHz. The HMC798 ALC4 eliminates the need for wire bonding, allowing use of surface mount manufacturing techniques.

Application

• Point-to-Point Radios• Point-to-Multi-Point Radios & VSAT• Test Equipment & Sensors• Military End-Use• SATCOM
