优势和特点

  Dual output: fO = 8.45 GHz to 9.3 GHz

  fO/2 = 4.225 GHz to 4.65 GHz

  POUT: 12 dBm

  Phase noise: −116 dBc/Hz at 100 kHz

  No external resonator needed

  RoHS compliant, 5 mm × 5 mm SMT package: 25 mm²

产品详情

The HMC1160 is a MMIC voltage controlled oscillator that integrates a resonator, a negative resistance device, and a varactor diode, and features a half frequency output.

Because of the monolithic construction of the oscillator, output power and phase noise performance are excellent over temperature.

Power output is 12 dBm typical from a 5 V supply voltage. The voltage controlled oscillator is housed in a RoHS compliant SMT package and requires no external matching components.

Applications

  Point to point and multipoint radio

  Test equipment and industrial controls

  VSAT
