The FAN54161UCX is a low loss direct charger which charges the battery safely at 6 A and provides active protection, regulation and monitoring features.Integrated Protection and Regulation features control a pair of MOSFETs to ensure that the FAN54161UCX output voltage and current stay within a safe programmed operating range. Configurable hardware based safety features turn off the MOSFET in the event of a fault and notify the system.An integrated 10−bit Analog−to−Digital Converter (ADC) provides real−time monitoring of input, output voltage, currents and temperature so that the system host or microcontroller can effectively use this information to optimize adapter and charger configuration.

• Integrated Back−to−Back Common Source N−channel MOSFETs with Combined RON = 11 mΩ
• Maximum Input Voltage Tolerance of +22 V
• Reverse Input Voltage Tolerance of −2 V
• External N−channel MOSFET Drive Capability with Tolerance up to+32 V
• Regulation Modes (Charge Current, Input Current, Output Voltage, Battery Cell Voltage)
• Hardware−based Safety Protections (Input Over-Voltage, Input Under-Voltage, Output Over-Voltage, Input Over-Current, Die Over-Temperature, Internal Switch Short)
