The AR1335 is a 1/3.2-inch CMOS active-pixel digital image sensor with apixel array of 4208H x 3120V. The AR1335 digital image sensor, featuresbreakthrough 1.1µm pixel technology that delivers superior low-lightimage quality through leading sensitivity, quantum efficiency and linearfull well. This allows image quality that rivals digital still cameras.With a sensor architecture focused on low power and a high Chief RayAngle (CRA) for low Z-heights, the AR1335 is ideal for smartphone andother mobile device applications. It incorporates sophisticated on-chipcamera functions such as windowing, mirroring, column and row skipmodes, and snapshot mode. It is programmable through a simple two-wireserial interface. The AR1335 sensor can generate full resolution imageat up to 30 frames per second (fps) and supports advanced video modesincluding 4K 30fps, 1080P 60fps and 720P 120fps.

• 13MP CMOS sensor with advanced 1.1µm pixel BSI technology
• Data interfaces: 2,3 and 4 lane MIPI
• Bit-depth compression available for MIPI: 10-8 and 10-6 to lower bandwidth
• 3D synchronization controls to enable stereo video capture
• 6.8 kbits one time programmable memory (OTPM)
• Programmable controls: gain, horizontal and vertical blanking, auto black level offset correction, frame size/rate, exposure, left-right and top-bottom image reversal, window size, and panning
• Two on-die phase-locked loop (PLL) oscillators for super low noise performance
• On-chip temperature sensor
• Bayer pattern horizontal down-size scaler
• Simple two-wire fast-mode+ serial interface
• Low dark current
• Interlaced multi-exposure readout enabling High Dynamic Range (HDR) still and video applications
• ON-chip lens shading correction
• Support for external mechanical shutter
• Support for external LED or Xenon Flash
• Extended Flash duration up to start of frame readout
• Die or CSP Package
• Mono or Color variations
