ON Semiconductor's AR0261 is a 2-megapixel sensor delivering native 1080p resolution with exceptional image quality and meets strict form factor requirements (z-height less than 3.5mm) for ultra-thin, full HD video applications within the Mobile, Tablet and Notebook market. This sensor has a 1/6-inch optical format and a new 1.4-micron pixel featuring ON Semiconductor A-PixHS(tm) technology to provide excellent low-light performance. The new sensor provides HD video at 1080p/60fps or 720p/60fps critical for sharp, clear video capture.

• 2 MP CMOS sensor with advanced 1.4um pixel BSI technology
• Data interfaces: 1 and 2 lane mobile industry processor interface (MIPI)
• Bit-depth compression available for MIPI Interface:10-8 and 10-6 to enable lower bandwidth receivers for full frame rate applications
• 3D synchronization controls to enable stereo video capture
• Interlaced multi-exposure readout enabling High Dynamic Range (HDR) still and video applications
• 8.8kbits one-time programmable memory (OTPM) for storing shading correction coefficients and module information
• Programmable controls: gain, horizontal and vertical blanking, auto black level offset correction, frame size/rate, exposure, left-right and top-bottom image reversal, window size, and panning
• On-chip dual phase-locked loop (PLL) oscillator structure for improved EMI characteristics
• Superior low-light performance
• Low dark current
• Simple two-wire serial interface
• On-chip lens shading correction
• Support for external mechanical shutter
• Support for external LED and xenon
