ADV7281A
10-Bit, 4× Oversampled SDTV Video Decoder with Differential Inputs
制造商:ADI/AD
产品信息
优势和特点
Worldwide NTSC/PAL/SECAM color demodulation support
One 10-bit ADC, 4× oversampling per channel for CVBS, Y/C, and YPrPb modes
6 analog video input channels with an on-chip antialiasing filter
Video input support for CVBS (composite), S-Video (Y/C), and YPrPb (component)
Fully differential, pseudo differential, and single-ended CVBS video input support
NTSC/PAL/SECAM autodetection
STB diagnostics on 2 video inputs
Up to 4 V common-mode input range solution
Excellent common-mode noise rejection capabilities
5-line adaptive 2D comb filter and CTI video enhancement
Integrated AGC with adaptive peak white mode
Fast switching capability
ACE
Downdither (8-bit to 6-bit)
Rovi copy protection detection
MIPI CSI-2 Tx output interface
Full featured VBI data slicer with WST support
Power-down mode available
2-wire, I2C-compatible serial interface
Qualified for automotive applications
−40°C to +105°C temperature grade
32-lead, 5 mm × 5 mm, RoHS compliant LFCSP
产品详情
The mobile industry processor interface (MIPI®) model of the ADV7281A (ADV7281A-M) has the same pinout as and is software compatible with the ADV7281-M.
The ADV7281A is a versatile one-chip, multiformat video decoder that automatically detects standard analog baseband\video signals and converts them into YCrCb 4:2:2 component video data streams.
The analog input of the ADV7281A features a single 10-bit analog-to-digital converter (ADC) and an on-chip differential to single-ended converter to accommodate the direct connection of differential, pseudo differential, or single-ended CVBS without external amplifier circuitry.
The standard definition processor (SDP) in the ADV7281A automatically detects PAL, NTSC, and SECAM standards in the form of composite, S-Video (Y/C), and component. The analog video is converted into a 4:2:2 component video data stream that is output via a MIPI CSI-2 transmitter (Tx) interface, hereafter referred to as MIPI Tx.
The ADV7281A offers short to battery (STB) diagnostic sense inputs and general-purpose outputs.
The ADV7281A is provided in a space-saving LFCSP surface-mount, RoHS compliant, package. The ADV7281A is rated over a −40°C to +105°C temperature range, making it ideal for automotive applications.
The ADV7281A must be configured in accordance with the I2C writes provided in the evaluation board script files.
Applications
Advanced driver assistance
Automotive infotainment
DVRs for video security
Media players
电路图、引脚图和封装图
