The 24AA014 is a 1Kb Serial EEPROM with operation down to 1.7V. The device is organized as a single block of 128 x 8-bit memory with a 2-wire serial interface. Low-current design permits operation with typical standby and active currents of only 1 uA and 1mA, respectively.

  Single-supply with operation down to 1.7V

  Low-power CMOS technology

  Hardware write protection for entire array

  100 kHz and 400 kHz clock compatibility

  Page write buffer for up to 16 bytes

  5 ms max. write cycle time

  1,000,000 erase/write cycles

  ESD protection > 4,000V
